COUGAR PSU ATLAS 650 80Plus Bronze 650W

Specifikacije

Informacije

Power device type POWER SUPPLY
Power device location PLUG-IN-MODULE
Form factor ATX
Input voltage AC 100-240 V
Input frequency 50/60 HZ
Rated input current 10 A
Maximum output power 650 W
Circuit protection OVER VOLTAGE, UNDERVOLTAGE, OVER CURRENT, SHORT CIRCUIT PROTECTION, OVER POWER
Power adapter and power supply features ACTIVE PFC, LOW NOISE
80 plus certification 80 PLUS BRONZE
Efficiency 89%
+3.3v 20 A (65 W)
+5v 20 A (65 W)
+12v 54.16 A (649.92 W)
-12v 0.3 A (3.6 W)
+5vsb 3 A (15 W)
20+4-pin main connector 1
4/8-pin +12v power connector 2
4-pin peripheral power connector 2
S-ata connector 6
6/8-pin pci express connector 2
Fans installed quantity 1
Fan diameter 120 MM
Maximum operating ambient temperature 40 °C
Minimum operating ambient temperature 10 °C
Maximum operating humidity 85 %
Minimum operating humidity 20 %
Maximum non-operating ambient temperature 70 °C
Minimum non-operating ambient temperature -40 °C
Maximum non-operating humidity 95 %
Minimum non-operating humidity 5 %
External color BLACK
Included accessories QUICK START GUIDE
Warranty products returnable Da
Warranty term (month) 24 MONTH(S)
Warranty validation criteria SERIAL NUMBER
Pack weight brutto (kg) 1.99 KG
Pieces in pack 1
Box weight brutto (kg) 18.6 KG
Packs in box 9
Package type BOX
Ean code 4710483774874

GTIN: 4710483774874

Šifra: CGR-AT650
